Tabla de tubería de diámetros mayores

Tabla de Especificaciones de Tubería de Diámetros Mayores

ESPESOR		mm			4.8	5.2	5.6	6.4	7.1	7.9	8.2	8.4	8.7	9.3
ESPESOR		in			0.188	0.203	0.219	0.250	0.281	0.312	0.322	0.330	0.344	0.365
DIÁMETRO NOMINAL		DIÁMETRO EXTERIOR		kg/m
mm	in	mm	in	kg/m
203	8	219.1	8.625		25.26	27.22	29.28	33.31		41.24	42.55		45.34
254	10	273.1	10.75		31.62	34.08	36.67	41.75					56.96	60.29
305	12	323.9	12.75		37.62	40.55	43.63	49.71	55.75	61.69		65.18	67.90
356	14	355.6	14		41.35		47.99	54.69	61.35	67.90			74.76
406	16	406.4	16		47.34	51.06	54.96	62.84	70.30	77.83			85.71
457	18	457.2	18					70.60	79.24	87.75			96.66
508	20	508	20					78.55	88.19	97.67			107.60
610	24	609.6	24					94.46	106.08	117.51			129.50
762	30	762	30					118.33	132.91	147.28			173.34
914	36	914.4	36					142.13	159.97	176.96			195.11
1219	48	1219.2	48										260.85

ESPESOR		mm			9.50	10.30	11.10	11.90	12.70	14.30	15.90	17.50	19.10	20.60	22.20
ESPESOR		in			0.375	0.406	0.438	0.469	0.500	0.562	0.625	0.688	0.750	0.812	0.875
DIÁMETRO NOMINAL		DIÁMETRO EXTERIOR		kg/m
mm	in	mm	in	kg/m
150	6	168.3	6.625		37.28
203	8	219.1	8.625		49.20
254	10	273.1	10.75				71.87
305	12	323.9	12.75		73.78	79.70	85.82
356	14	355.6	14		81.25	87.79	94.55	100.94
406	16	406.4	16		93.27	100.70	108.49	115.86	123.30
457	18	457.2	18		105.10	113.62	122.43	130.78	139.20	155.87
508	20	508	20		117.02	126.53	136.37	145.70	155.12
610	24	609.6	24		140.88	152.37	164.26	175.54	186.94	209.50	232.66	255.24
762	30	762	30		176.84	191.11	206.09	220.30	234.67	263.12	292.18	320.93	349.02	376.98	405.54
914	36	914.4	36		212.59	229.76	247.31	264.94	282.27	316.11	351.70	386.45	420.42	454.27	488.86
1219	48	1219.2	48		284.24	307.30	331.52	354.52	377.79	423.94	471.14	517.92	563.70	609.36	656.06

CED.10CED.20CED.30CED.40ESTÁNDAR
